IP65 Waterproof dimmable constant voltage LED Power Supply 100W

Product characteristic

  • Power Range: 60W-300W
  • Multiple protection circuits: Short Circuit (SCP), Over Current (OCP), Over Voltage (OVP), and Over Temperature (OTP) Protection.
  • International universal range input voltage (100-277VAC).
  • IP65 waterproof rating, used in dry, wet, rainy etc other environments.
  • 3-in-1 dimming function (compatible with 0-10V, resistance, PWM).
  • Three installation methods: one junction box, two junction boxes or no junction box for optional.
  • Silent glue filled, waterproof and dustproof.
  • 5 years warranty.



Product application

  •  Advertising light boxes
  • Advertising signs
  • LED strips module
  • LED Strip Lighting (Cove, Under-Cabinet, Accent)
  • Outdoor Landscape & Pathway Lighting
  • LED Signage & Channel Letters
  • Architectural Lighting
  • Garden lighting
  • Pool & Deck Lighting (when housed appropriately)
  • Any 12V /24V/36V/48V DC Constant Voltage LED system



Safety certification

ETL      FCC      CE       Roths

Category:

Description

Landscape Lighting Power Supply 12V 24V

■ Universal AC input/full range(100-277V)

■  Efficiency up to 91%,

■  Protections:short circuit/over load/over voltage/over temperature

■  IP65 design for indoor or outdoor installation

■  It can be used in dry,wet and rainy environment

■  The lights turn off during the day and turn on at night standby power:0.2-0.4W

■  Three in one dimming function, (compatible with 0-10V, resistor, PWM)

■  Up to 50000-hours life time

■  Compliance to worldwide safety regulation for led lightings.

■ 5 years warranty.

■ Non-dimming function for optional.



billboard power supply
billboard power supply



Power Model Input voltage (AC) Output voltage (DC) Output current Efficiency PF Size (mm) Waterproof grade Warranty Certificate
60W PSD-HP060-C12 100-277V 12V 5A 87% 0.5 148*65*36 IP65 5 year ETL FCC CE
PSD-HP060-C24 100-277V 24V 2.5A 88% 0.5 148*65*36 IP65 5 year ETL FCC CE
100W PSD-HP100-C12 100-277V 12V 8.3A 89% 0.5 148*65*36 IP65 5 year ETL FCC CE
PSD-HP100-C24 100-277V 24V 4.15A 91% 0.5 148*65*36 IP65 5 year ETL FCC CE
150W PSD-HP150-C12 100-277V 12V 12.5A 89% 0.5 148*65*36 IP65 5 year ETL FCC CE
PSD-HP150-C24 100-277V 24V 6.25A 90% 0.5 148*65*36 IP65 5 year ETL FCC CE
200W PSD-HP200-C12 100-277V 12V 16.6A 92% 0.95 238*65*36 IP65 5 year ETL FCC CE
PSD-HP200-C24 100-277V 24V 8.3A 92% 0.95 238*65*36 IP65 5 year ETL FCC CE
300W PSD-HP300-C12 100-277V 12V 25A 92% 0.95 238*65*36 IP65 5 year ETL FCC CE
PSD-HP300-C24 100-277V 24V 12.5A 92% 0.95 238*65*36 IP65 5 year ETL FCC CE
200W PSD-HP200-C12 200-240V 12V 16.6A 92% 0.5 218*65*36 IP65 5 year CE
PSD-HP200-C24 200-240V 24V 8.3A 92% 0.5 218*65*36 IP65 5 year CE
300W PSD-HP300-C12 200-240V 12V 25A 92% 0.5 218*65*36 IP65 5 year CE
PSD-HP300-C24 200-240V 24V 12.5A 92% 0.5 218*65*36 IP65 5 year CE

Note: Adding one junction box increases the power supply length by 62MM. Adding two junction boxes increases the power supply length by 126MM.
